Temperature Sensors




Types of Thermocouples : 'K' (Chromel - Alumel ) ,'J' (Iron- Constantan). 'T' (Copper-Conslantan), 'E' (Chromel- Constantan), 'R' (Pt-Pt-13%-Rh) ; 'S' (Pt-p 10%-Rh), 'B' (Pt-
13%-Rh-Pt-6%-Rh) in Simplex. Duplex and Triplex.

Types of Resistance Temperature Detectors : Pt-50, Pt-100, Pt 500, Pt-1000, NI-100, Cu-2000 in Simplex, Duplex and Triplex.

Types of Insulations :
Ceramic Insulation and Mineral Insulation.

Types of Junctions :
Grounded, Ungrounded (Isolated),

Types of Sheaths :
Mild Steel, SS-304, SS-316, SS-310. SS- 446. Inconel -600, Inconel - 800. Titanium. Cast- Iron, Nickel, Ceramic (610), Recrystlised Alumina (KER-710), etc.

Shapes & Sizes :
As per your requirement or application.

Mounting Accessories :
Thermocouple and RTD connectors, BSP / NPT / UNF/ Metric threaded Male Female adjustable ferrule fitting in Mild Steel/ Stainless Steel-304/316/Brass etc. All type of flanges available as per standard table and as per your requirement or application considering pressure in Mild Steel, Carbon Steel, Stainless-304/316.

Temperature Sensors

Selection of Thermocouple Type as per Temperature

Temp.range in C
Type of Thermocuple
Resolution in C
-40 to 760
'J' (Iron-Constantan)
1
- 40 to 1260
'K' (Chromel-Alumel)
1
- 184 to 371
'T' (Copper-Constantan)
1
- 50 to 1741
'R' ( Pt-Pt-13%-Rh)
1
- 50 to 1767
'S' ( Pt-Pt-13%-Rh)
1
- 200 to 550
( 100 othms RTD Pt-100 Bullb)
1
