Vibrator Controllers CUH Make - SDVC21-S:6A


We are Authorised Dealer, Distributor, Supplier of Vibrator Controllers CUH Make - SDVC21-S:6A and our setup is situated in Pimpri Chinchwad near Pune, Maharashtra, India.


SDVC21-S:6A

FEATURES :
Automatic Voltage Regulation: Eliminate feed speed variation caused by mains voltage fluctuation.
Soft Startup: In order to avoid sudden shock to the feed material and vibratory feeder, the controller can gently increase output voltage from 0 to the preset value when startup.
Preset Speeds: 4 preset feed speeds can be stored and output by external short-circuit signal.
Remote ON/OFF Control: The controller has 2 groups of ON/OFF control pins. Switch sensor or PLC can be connected to them to turn on/off the controller.
Photoelectric ON/OFF Control: The CUH Intelligent Photoelectric Sensor can be connected to turn on/off the controller.
Remote Speed Control: Output Voltage of the controller can be adjusted remotely by an external potentiometer, a PLC, or a 1-5V DC signal.
DC Control Output: The controller can output low voltage DC power associated with logical relation setting of the ON/OFF Control to drive a solenoid, an electrical relay or other external devices.
Overheat Protection: If internal temperature of the controller gets too high, the controller will stop its output to protect itself.
Overcurrent Protection: If output current exceeds its rated value by mis-operation, the controller will stop its output to protect the controller and vibratory feeder.
Short-Circuit Protection: If output of the controller is short-circuited, the fuse inside the controller will be blown to protect the controller and vibratory feeder from further damage.



Optional Accessorie
Optional Accessorie

  • Intelligent Photoelectric Sensor (1.2m)




Dimensions: 190*55*100 (L*W*H, mm)

Weight: 550g (without accessory)



TECHNICAL SPECIFICATION

      ITEM

Range



Unit



Description

Min

Max

Input voltage

85

260

V

AC RMS Value

Output voltage

0

260

V

Less than Input voltage

Output Current

0

6

A





Output Frequency

50/100

Hz

Mains Frequency is 50Hz

60/120

Hz

Mains Frequency is 60Hz

OutPut Power

0

1320

VA



Output Waveform

Tangent Sine





Viltage Adjestment Accuracy 1 v
ON/OFF delay 0 20 s
ON/OFF Delay Accuracy 0.1 s
Soft Startup Time 0 10 s
DC Control output Voltage 22 26 V DC output associated with ON/OFF control
DC Control output current 0 200 mA
Stand by Power Consumption 1.5 3 w
Display Method 5 Digit LED Digital Tube







Control Method

1-5 V

Remote Speed

Control Voltage

Standard TTL Electric Level   Switching Signal
/   6 Buttons + LED screen

Work Space
Temperature

-10

60

°C



Non-Condensing

Work Space Humidity

10

85

  %
